More than fifty years after the last crewed Moon landing, a new lunar race is unfolding – with NASA’s recent Artemis II mission and the United States, Russia, and China all aiming to establish permanent bases on the Moon. Unlike Apollo’s multiple landing sites, today’s missions are focused on a single destination: the Moon’s South Pole.

Spaceflight pioneer Robert H. Goddard proposed over a century ago that ice might exist at the Moon’s poles, a theory increasingly supported by evidence gathered over the past two decades. In space exploration, ice is a valuable resource, offering potential for drinking water, irrigation, rocket fuel production, and insights into the history of celestial bodies.

Now, Weizmann scientists, in collaboration with researchers in the United States, have found new evidence that ice has been steadily accumulating at the Moon’s poles for at least 1.5 billion years. Their study, recently published in Nature Astronomy, identifies ancient “cold traps” on the lunar surface and designates them as prime targets for future missions.

Unlike Earth, whose tilted axis causes the Sun’s position in the sky to change throughout the year, the Moon has almost no tilt, and the Sun is always positioned approximately above its equator. As a result, sunlight cannot reach and warm the deep, steep craters at the lunar poles, which are known as “permanently shadowed regions.”

This was not always the case. In the distant past, the Moon had a much greater axial tilt, but over the last several billion years it has been straightening up. In 2023, researchers showed that as the Moon’s tilt decreased, more and more craters near the poles became permanently shadowed, and cooled dramatically. By calculating when each crater lost its exposure to sunlight, they were able to deduce the “age” of each permanently shadowed region.

In the new study, Prof. Oded Aharonson of Weizmann’s Earth and Planetary Sciences Department and his collaborators – Prof. Paul Hayne of the University of Colorado Boulder and Dr. Norbert Schörghofer of the Planetary Science Institute in Honolulu – set out to examine whether there is a connection between the age of a permanently shadowed region and the proportion of its area covered by ice.

Ice reflects more ultraviolet light at certain wavelengths than the Moon’s rocky surface, making it possible to infer where it is located. Ultraviolet light provides an advantage because it emanates not only from the Sun but also from distant stars, and it can enter permanently shadowed areas. The researchers analyzed data collected by an ultraviolet-sensitive instrument aboard NASA’s Lunar Reconnaissance Orbiter, which has been orbiting and mapping the Moon since 2009.

“We found that the earlier a region became shadowed, the larger the area that was able to accumulate ice,” says Aharonson. “This trend began at least 1.5 billion years ago and has continued even over the past 100 million years. This suggests that ice has been building up on the Moon from a nearly continuous source – or sources – rather than through a single event such as a large comet impact.”

For ice not only to form on the lunar surface but also to persist for hundreds of millions or even billions of years without evaporating, extremely low temperatures are required – around minus 256 degrees Fahrenheit. Regions that maintain such temperatures year-round are known as cold traps. While many permanently shadowed regions qualify as cold traps, some do not, because surrounding walls can radiate heat into the crater.

To identify the most promising locations for finding lunar ice, the researchers used geometric calculations to determine which permanently shadowed regions also function as cold traps, and when in the Moon’s history they acquired this status.

“The longer a given region has been a cold trap, the more ice it has accumulated,” Aharonson explains. “In most cases, a crater became shadowed and turned into a cold trap at the same time – but not always. For example, Shackleton Crater has been shadowed for about 3.5 billion years and was considered a promising site in the search for lunar ice. We discovered, however, that it only became a cold trap around 500 million years ago. To identify targets for future missions, we searched for the oldest cold traps and found several extensive ones more than 3.3 billion years old near the Moon’s South Pole.”

These findings are especially significant since locating and sampling lunar ice is one of the primary goals of NASA’s future crewed Artemis missions, scheduled to land astronauts at the Moon’s South Pole. NASA’s long-term vision includes establishing a permanent lunar base to serve as preparation – and possibly a transit station – for future crewed missions to Mars.

“The gold-standard proof of the existence of ice on the Moon would be a sample of it,” says Aharonson. “It would allow us to compare the chemical composition of water on the Moon with that on Earth, and to assess whether – and how – crewed lunar missions could make use of this resource.”

The study supplies motivation for follow-up exploration of the most ancient cold traps and provides guidance on the best locations to target, such as Haworth Crater, one of the newly identified ancient cold traps. “Future spacecraft missions would be able to collect extensive data on the ice from the crater’s surface, and rovers would be able to approach, enter, and sample the ice deposits,” says Hayne.
